Project Name: Steel Structure Garment Factory
Location: Mekele, Tigrey, Ethiopia
Area: 100000 sqm
Project Time: 2015
The steel structure factory project contains 2 garment workshops, office building, staff dormitory and steel villa.
Garment factory details:
1. Size:
1# garment factory workshop building 138*390*8.9m (Length* Width* Eave Height)
2# garment factory workshop building 138*240*8.9m (Length* Width* Eave Height)
2. Main steel structure: H column and beam Q345B,two coats of mid-grey paint
3. Purline: c-shaped and Z- shaped steel, Q235,Galv.
4. Roof system: corrugated galvanized roofing steel sheet, 0.5mm + EVA + Galvanized Steel Wire Netting
5. Wall system: corrugated galvanized exterior wall steel sheet, 0.5mm + 75mm fiber glass wool + Corrugated galvanized interior wall steel sheet,0.4mm
6. Erection: send our engineers to guide installation on site.
